Toyotomi KR-47

The Toyotomi Wick Heater KR-47 features a Double Clean burner with a heating capacity of 4.70 kW, providing clean, efficient, and economical heat without installation. Its flueless burning system requires only two batteries for ignition, making it extremely easy to operate. Designed to heat spaces up to 180 m³, it comes with multiple safety features, including a durable glass fiber wick, triple safety shut-off, and spark ignition system. Perfect for indoor or outdoor use, the KR-47 delivers reliable warmth for camping, patios, or creating a cozy atmosphere at home.

SKU: KR-47
EAN: 4963505711597

Toyotomi KR-47
Toyotomi KR-47

Can’t find the information you are looking for, or have an inquiry?
Visit our Customer Service page for contact, other documentations or visit Become a Partner page for business inquiries.

Includes

Close-up of Toyotomi durable carbon glass fiber wick for paraffin wick heater

Durable Carbon Glass Fiber Wick

The durable carbon glass fiber wick offers a longer lifespan than traditional cotton wicks. It resists burning out, even if the heater runs out of fuel.

Built-up tar deposits can be easily removed through a dry-burn cleaning process, helping maintain performance and extend wick life.

Double Clean

The Double Clean developed by Toyotomi uses two burning chambers. The first chamber, called the primary chamber, ignites and burns most of the fuel and gives off radiant heat. The remaining unburned fuel is passed to the secondary chamber, there it is further burned, producing additional convective heat.

It results that the Double Clean heater reduces emission levels far below those of other paraffin heaters by the use of the Double Clean Heat Chamber.

Detailed diagram of Toyotomi HVAC mechanism for optimal climate control.

Double Tank

The double wall tank construction prevents fuel leakage for safety even when the heater is tipped over.

Manual Syphon Pump

All of our heaters include a manual syphon pump as a standard accessory in every box, used to refill your heater with fuel. This simple and practical tool makes fuel transfer easy and helps prevent spilling during refueling.

Flexible medical feeding tube with red connector for precision and safety.

Additional information

Heating Capacity min.

3.80 kW

Heating Capacity max.

4.70 kW

Suitable Space

73 – 180 m³

Fuel Consumption min.

0.393 liter/hour

Fuel Consumption max.

0.490 liter/hour

Burning Time min.

15.30 hours

Burning Time max.

19.10 hours

Tank Capacity

7.5 liter

Net Weight

12 kg

Gross Weight

13.5 kg

Dimensions Unit

474×474×561 mm

Dimensions Packaging

495×495×615 mm

Certification Mark

CE

Fuel

Paraffin

Color

Black

Warranty

5 years
